Measuring range: 0 ~ 6000 mm
Accuracy: + / - 10 mm - 16 mm
Double column diameter: 10 mm to 16 mm
Nominal pressure: 1.6 MPa to 2.5 MPa
Nominal drift diameter: 150 mm
A medium density: 0.7 g/cm3 or special requirements (up to 0.45 g/cm3)
Medium temperature: - 20 ~ + 250
Pick up liquid material: 1 cr18ni9ti OCr18Ni9 (304)
Medium temperature: 20 or less pa. S
Environmental vibration: the rate of 25 hz or less amplitude of 0.5 mm or less
Follow the speed: 0.08 m/s or less
The flange standard: HG20592 ~ 2063-2063
Alarm, remote transmission device: the technical parameters and UHZ - 52 z series is the same.
SXG series digital display control alarming device, column display alarming device as shown in the manual adjustment.
